ATP Series - Max 35 Floors Automated Tower Parking System

What is a tower parking system capable of? It can be tall, up to 35 floors; can be wide, up to 6 parking spaces per floor; and can be half-underground by adding extra floors in pit. ATP series is the magic tower that extremely maximizes the usage of limited land in small ground space and improves the experience of car parking. Compared to the traditional platform type with complete deck, our newly developed comb-type platforms greatly simplify the exchanging process and effciently shortens the waiting time. A turntable is optionally available on the ground floor to increase the parking effciency further.
sharethis sharing button
  • ATP

  • Mutrade




Mutrade ATP series car parking tower is a state-of-the-art automated parking system featuring a steel framework. Designed to accommodate 20 to 70 cars on multiple levels using a high-speed lifting mechanism, this technology optimizes urban space utilization while enhancing parking convenience. Accessing a desired parking space is effortless for users, who can swipe an IC card or input the space number on the operation panel. Integration with a parking management system further ensures swift and automated retrieval of the selected platform to the entrance level of the parking tower.

- Smart parking system for small footprint areas

- High tower up to 35 levels for 70 vehicles

- Fit for both sedans and SUVs

- Lifting capacity: 2350kg

- Vehicle size: Length 5300mm, Height up to 2050mm

- Wide tower possible: max 6 parking spaces per floor

- Comb pallet design greatly shortens exchanging time

- Super-high speed lifting system, up to 120m/min

- Both stand-alone type and built-in type available

- Pit version is also available

- Turntable is optional on ground floor

- Premium safety ensured by multi safety devices

- Smart operation via ID card


Model ATP-35
Levels 35
Lifting capacity 2500kg / 2000kg
Available car length 5000mm
Available car width 1850mm
Available car height 1550mm
Motor power 15Kw
Available voltage of power supply 200V-480V, 3 Phase, 50/60Hz
Operation mode Code & ID card
Operation voltage 24V
Rising / descending time <55s

Dimensional Drawing

fully automated multilevel tower parking system

fully automated multilevel tower parking system

fully automated multilevel tower parking system

Main Features






Product Category


We develop, design and manufacture mechanical parking equipment with our own advanced technology and kept consistent high quality.
